The J.W.Walker organ was first installed on the floor of the southern (liturgical northern) transept in 1860. It was shifted to a new gallery in the opposite transept in 1974. While the original cone-pallet chests were retained, the action was electrified, the Pedalboard enlarged, and a new Choir Organ added, with the resulting specification:
GREAT CHOIR
16′ Bourdon 8′ Lieblich Gedackt(orig.Great)
8′ Open Diapason 8′ Dulciana (orig.Great)
8′ Violin Diapason 4′ Koppel Flute
8′ Stopped Diapason 2′ Recorder
4′ Principal 8′ Vox Humana
4′ Chimney Flute 8′ Oboe Schalmei
2 2/3′ Twelfth 8′ Tuba(unenclosed)
2′ Fifteenth
II Mixture (19.22)
8′ Trompette SWELL PEDAL
8′ Horn Diapason
8′ Lieblich Gedackt 16′ Open Wood
8′ Salicional 16′ Bourdon
8′ Voix Celeste 16′ Echo Bourdon(from Great)
4′ Gemshorn 8′ Bass Flute
4′ Suabe Flute 8′ Violin Cello
2′ Piccolo 4′ Octave Flute
III Mixture (22.26.29) 4′ Schalmei
8′ Oboe
8′ Cornopean
4′ Clarion
ACCESSORIES
Swell Tremulant
Swell Sub Octave
Swell Super Octave
Swell to Great
Swell to Great Sub
Swell to Great Super
Swell to Pedal
Swell to Choir
Great to Pedal
Choir to Great
Choir to Pedal
Choir Sub Octave
Choir Super Octave
Tremulants to Swell and Choir
Great to Pedal Combinations Coupled
Combination Pistons (preset)
Great: 4 pistons
Swell: 4 pistons
Pedal: 4 pistons
Choir: 3 pistons
GREAT (new slider soundboards)
16′ Bourdon
8′ Open Diapason
8′ Violin Diapason
8′ Stopt Diapason
4′ Principal
4′ Chimney Flute
2 2/3′ Twelfth
2′ Fifteenth
1 3/5′ Seventeenth
III Mixture
8′ Trumpet
GREAT
